OGM-25SS OGM-50SS Stainless Steel Oval Gear Flow Meter-Mechanical
The KOEO OGM Stainless Steel Flow Meter is designed for flow rates ranging from 20 to 300 L/min(5.2-79.3GPM), ensuring precise flow measurement. The OGM Series delivers an accuracy of ±0.50% of the true reading within a compact design. This flow meter does not require flow conditioning and is capable of operating under high pressure and temperature conditions.
.Construction: Cast Stainless Steel
.Seals: FEP Encapsulated
.Maximum Flow Rate:300L/min(79.3 GPM)
.Accuracy:±0.50%
.Repeatability:±0.03%
.Temperature Range: Up to 80℃ (176°F)
.Calibration:1-point factory calibration as standard, with additional calibration points available upon request
|
Model |
OGM-25SS |
OGM-50SS |
|
Flow Rate |
20-120L/min |
30-300L/min |
|
Inlet/Outlet |
1"(25mm) |
2(50mm) |
|
Accuracy |
±0.5% |
|
|
Repeatability |
0.03 |
|
|
Max. Pressure |
18Bar |
|
|
Max. Viscosity |
1000cps |
|
|
Unit |
Liters or US.Gallon |
|
