YB Series Rotary Sliding Vane Pump
.Unique sliding vane pump design self-adjust for wear to maintain flow rates Excellent at self-priming, eliminates expensive priming systems
.Extended dry-run capability, eliminates nuisance current monitoring systems
.Sliding vane design provides sustained performance and trouble-free operation
.Easy maintenance: vanes can be easily replaced without removing the pump from the piping system
.High suction lift abilities and line-stripping capabilities to completely empty tanks, and piping of fluid
.Low maintenance and low life-cycle costs, pumps are renewable and repairable
.Solids handling, provided by large displacement and slow internal velocities
.Thin to thick fluid viscosity flexibility, eliminates expensive heating systems
.Highly efficient, sliding vane pumps require less horsepower than other pumps, meaning spending less on motors initially and less on electricity to power the pump
|
Model |
Diameter |
Flow Rate@400rpm L/min(Gal/min) | Flow Rate@450rpm L/min(Gal/min) | Flow Rate@500rpm L/min (Gal/min) | Flow Rate@550rpm L/min (Gal/min) | Flow Rate@600rpm L/min (Gal/min) | Flow Rate@650rpm L/min (Gal/min) |
| YB-50 | 2"(50mm) | 150 (39.6) | 180 (47.6) | 210(55.5) | 240(63.4) | 270 (71.3) | 300 (79.3) |
| YB-65 | 2.5"(65mm) | 310(81.9) | 350(92.5) | 390(103.0) | 430(113.6) | 465 (122.8) | 500(132.1) |
| YB-80 | 3"(80mm) | 600(158.5) | 680(179.6) | 760(200.7) | 840(221.9) | 920(243.0) | 1000(264.2) |
| YB-100 | 4"(100mm) | 1530 (404.2) | 1900(501.9) |
