OGM-25P SSOGM-50P SS Stainless Steel Oval Gear Flow Meter-Pulse
The OGM-25P SS and OGM-50P SS are suitable for flows between 20-300L/min(5.2-79.3GPM), providing highly accurate flow measurement performance. It offers ±0.50% accuracy of true reading in a compact footprint, requiring no flow conditioning and with high pressure and temperature capabilities.
.Construction: Stainless Steel
.Maximum Flow Rate:300 L/min (79.3GPM)
.Accuracy:±0.50%
.Repeatability: Exceptional, at ±0.03%
.Temperature Range: Up to 120℃ (248°F)
|
Model |
OGM-25P SS |
OGM-50P SS |
|
Flow Rate |
20-120L/min |
30-300L/min |
|
Inlet/Outlet |
1"(25mm) |
2(50mm) |
|
Accuracy |
±0.5% |
|
|
Repeatability |
0.03 |
|
|
Max. Pressure |
18Bar |
|
|
Max. Viscosity |
1000cps |
|
