DTP-45 DC Diesel Pump
The DTP-45 DC diesel pump is a robust 12V/24V dual-voltage fuel transfer solution featuring self-priming capability high flow rate and portable design ideal for trucks generators boats farms and emergency refueling with optional flow meter and nozzle kit.
- Max. Flow Rate 45 L/min(12Gal)
- Outlet 3/4"(19.05mm)
- Inlet 3/4"(19.05mm)
- Voltage 12V or 24V
- Power 150W or 180W
- Suction 3m
- Head 10m
.Cast iron pump body finished with anti-corrosion paint
.Vane pump with sintered steel rotor and acetal resin vanes
.By-pass valve incorporated in the pump body.
.Used in intermittent service with 30-minute work cycles
.Fuse for option
|
Model |
DTP-45 DC |
|
Max. Flow Rate |
45L/min(12Gal) |
|
Outlet |
3/4"(19.05mm) |
|
Inlet |
3/4"(19.05mm) |
|
Voltage |
12Vor 24V |
|
Power |
150W or 180W |
|
Suction |
3m |
|
Head |
10m |
|
IP Class |
IP55 |
