.Cast iron pump body finished with anti-corrosion paint
.Vane pump with sintered steel rotor and acetal resin vanes
.By-pass valve incorporated in the pump body.
.Used in intermittent service with 30-minute work cycles
.Equipped with a metal protective frame for enhanced durability
.Features a fan for cooling, ensuring a superior temperature control system
|
Model |
DTP-80 DC |
|
Max. Flow Rate |
80L/min(21Gal) |
|
Outlet |
1"(25mm) |
|
Inlet |
1"(25mm) |
|
Voltage |
12Vor 24V |
|
Power |
300W or 380W |
|
Suction |
3m |
|
Head |
10m |
|
IP Class |
IP55 |
